Best Way to Load & Convert XML Data to Oracle Tables

by Maciek

Maciek is the Co-founder of Sonra. He has a knack for turning messy semi-structured formats like XML, JSON, and XSD into readable data. With a brain wired for product and data architecture, Maciek is the magic ingredient to making sure your systems don’t just work—they shine.

Published on March 4, 2024
Updated on November 20, 2024

It’s very easy to get lost in the Oracle features for working with XML. The following questions come up frequently:

What are my options for working with XML in Oracle?
What option is suitable for my use case?

In this blog post we shed some light on these questions by examining the various Oracle XML features and making recommendations which option to pick for your use case.

We deep dive into the following topics

How to store XML inside the Oracle database using XMLTYPE and CLOB
How to load and insert XML data to Oracle tables
How to read XML from XMLTYPE or CLOB
How to parse and convert XML to Oracle tables (relational format)
How to extract values from XML
How to fully automate the XML conversion process from XML to Oracle tables

Enjoy the article

Oracle also provides XSD support. You can register an XSD and use it to validate your XML.

For those in a hurry we have compiled the key takeaways.

Key takeaways

Oracle XML-DB is the name of the bundle of features that developers use to build XML applications on Oracle.
You can store XML data inside an Oracle table as XMLTYPE or CLOB.
XMLTYPE is the recommended data type as it has dedicated support for XML such as XMLTABLE, XSD, XMLINDEX etc.
You have four options for loading XML to an Oracle table.
- INSERT INTO…SELECT (IIS) is useful for ad hoc queries and testing
- SQL Loader is the recommended approach for bulk loads and production implementations
- External tables are another option but not recommended as they do not support XMLType
You have three main options to query and read XML data in Oracle.
- XMLTABLE which is part of SQL/XML. This is the recommended way to read XML data in Oracle
- XQuery is useful for complex and niche requirements
- The EXTRACT and EXTRACTVALUE functions are deprecated and not recommended
Querying XML on the fly is commonly known as schema on read. It is a good approach for sporadic ad hoc querying of XML.
Converting XML to Oracle tables in a relational format is recommended over the schema on read approach where you frequently query the data. This is known as schema on write.
Using the schema on write approach you can use SQL to query the data previously locked away in XML in standard Oracle tables
For complex XML requirements with deeply nested XML, XSDs or XML that is based on industry data standards we recommend an automated approach using an XML converter.
No code XML conversion eliminates manual coding and simplifies complex XML parsing. Flexter is Sonra’s enterprise XML conversion tool. Find out more about Flexter, try it out yourself for free, or read up on an example of no code XML parsing on Oracle.

Storing XML in the Oracle database

You can directly store XML documents inside the Oracle database. You have two basic options. You can store the data as an XMLType or a CLOB data type.

XMLType

XMLType was introduced in Oracle 9i. It is a built-in data type specifically designed to store XML data inside the Oracle database.

XMLType is the recommended way to store XML inside Oracle as it has native support for XML:

XSD support: Supports XML Schema validation, ensuring that the XML data adheres to a predefined structure.

Optimised storage: Oracle optimises the storage of XMLType for efficient querying and retrieval. It also supports binary XML storage, which is more space-efficient and faster for many operations.

Indexing: You can create XML-specific indexes (XMLIndex) on XMLType columns to improve query performance.

CLOB for XML

CLOB is a versatile data type in Oracle used to store large text data. It can store XML as plain text but lacks the XML-specific optimisations and features of XMLType

The main advantage of the CLOB data type versus XMLType is its flexibility. You can store any type of large text data, not just XML.

XMLType vs. CLOB for XML

Here is a summary comparison of XMLType to CLOB

Feature	XMLType	CLOB
XML Support	Native XML support with schema validation, XPath, and XQuery	No native XSD support
Storage Optimization	Optimised for XML storage, supports binary XML	General text storage, not optimised for XML
Indexing	Support for XMLIndex	No support for XMLIndex
Performance	Better performance for XML queries and manipulations	Slower performance for XML operations
Complexity	More complex to set up and manage	Simpler to use and manage
Flexibility	Designed for XML only	Can store any large text data

Loading XML data into an Oracle table

Inserting XML into an Oracle table

This method involves inserting XML data row by row into Oracle database tables. It gives flexibility but has slow performance for large datasets.

It is great for ad hoc use cases where you need to quickly load XML data into an Oracle table for testing and on the fly querying. It is not recommended for production use cases.

Step 1. Create a table with XMLType data type to store XML data.

CREATE TABLE xml_tab (
  id 	NUMBER,
  xml_data  XMLTYPE
);

CREATE TABLE xml_tab (

id NUMBER,

xml_data XMLTYPE

);

Step 2. Insert XML text into the ‘xml_tab’ table

INSERT INTO xml_tab (id, xml_data)
VALUES (1, XMLType('<University id="TUD">
    <Faculty id="Engineering">
        <Department id="ComputerScience">
     	<Course>Introduction to Programming</Course>
     	<Course>Algorithms and Data Structures</Course>
        </Department>
        <Department id="ElectricalEngineering">
     	<Course>Circuit Analysis</Course>
            <Course>Electromagnetics</Course>
     	<Course>Control Systems</Course>
        </Department>
        <ResearchGroup id="ArtificialIntelligence">
     	<Project>Machine Learning Advances</Project>
     	<Project>Neural Network Optimization</Project>
     	<Project>AI Ethics and Society</Project>
        </ResearchGroup>
        <ResearchGroup id="Nanotechnology">
     	<Project>Nano-materials Engineering</Project>
     	<Project>Quantum Computing</Project>
        </ResearchGroup>
    </Faculty>
    <AdministrativeUnit id="Library">
        <Service>Book Lending</Service>
        <Service>Research Assistance</Service>
    </AdministrativeUnit>
    <AdministrativeUnit id="IT">
        <Service>Campus Network</Service>
        <Service>Helpdesk</Service>
    </AdministrativeUnit>
</University>
'));

INSERT INTO xml_tab (id, xml_data)

VALUES (1, XMLType('<University id="TUD">

<Course>Introduction to Programming</Course>

<Course>Algorithms and Data Structures</Course>

</Department>

<Course>Circuit Analysis</Course>

<Course>Electromagnetics</Course>

<Course>Control Systems</Course>

</Department>

<Project>Machine Learning Advances</Project>

<Project>Neural Network Optimization</Project>

<Project>AI Ethics and Society</Project>

</ResearchGroup>

<Project>Nano-materials Engineering</Project>

<Project>Quantum Computing</Project>

</ResearchGroup>

</Faculty>

<Service>Book Lending</Service>

<Service>Research Assistance</Service>

</AdministrativeUnit>

<Service>Campus Network</Service>

<Service>Helpdesk</Service>

</AdministrativeUnit>

</University>

'));

SELECT * FROM xml_tab

1	SELECT * FROM xml_tab

Loading XML files with SQL*Loader

SQL*Loader is a utility provided by Oracle that enables high-speed importing from XML files into Oracle database tables. It allows for efficient loading of large volumes of data in various formats, including XML.

SQL*Loader is the recommended tool to load XML files into Oracle tables. External tables only support the CLOB data type when loading XML files but not the more advanced XMLType data type which has specifically been created for storing XML.

When using SQL*Loader you specify a control file that defines the data format and mapping to the database table.

Step 1. Create a table with XMLType data type to store XML data.

CREATE TABLE xml_tab(
FILENAME VARCHAR2(255),
xml_data XMLTYPE
)

CREATE TABLE xml_tab(

FILENAME VARCHAR2(255),

xml_data XMLTYPE

)

Step 2. Prepare a control file (.ctl) for the SQL*Loader

LOAD DATA
INFILE *
REPLACE
INTO TABLE xml_tab
FIELDS TERMINATED BY ',' TRAILING NULLCOLS
(
    FILENAME,
    xml_data  LOBFILE(FILENAME) TERMINATED BY EOF
)
BEGINDATA
/home/oracle/Downloads/DUMPS/sample.xml

LOAD DATA

INFILE *

REPLACE

INTO TABLE xml_tab

FIELDS TERMINATED BY ',' TRAILING NULLCOLS

(

FILENAME,

xml_data LOBFILE(FILENAME) TERMINATED BY EOF

)

BEGINDATA

/home/oracle/Downloads/DUMPS/sample.xml

Step 3. Run below SQL*Loader command to load sample.xml file into the xml_tab1 table.

$ sqlldr system/oracle@orcl control=control_file.ctl log=loader_log.log

SQL*Loader: Release 11.2.0.4.0 - Production on Fri Feb 2 10:06:46 2024
Copyright (c) 1982, 2011, Oracle and/or its affiliates.  All rights reserved.
Commit point reached - logical record count 1

$ sqlldr system/oracle@orcl control=control_file.ctl log=loader_log.log

SQL*Loader: Release 11.2.0.4.0 - Production on Fri Feb 2 10:06:46 2024

Commit point reached - logical record count 1

SELECT * FROM xml_tab

1	SELECT * FROM xml_tab

Loading XML files with External Tables

External tables in Oracle offer a convenient way to access data stored in external files, treating them as if they were regular tables within the database. While DML operations aren’t supported on external tables, they work well for querying, joining, and sorting operations. XML files can integrate into a table as a CLOB column (XMLType data type is not supported for external tables). Once the external table has been created we can query the data, e.g. by creating Views.

This integration facilitates blending of XML data with relational data in Oracle databases. External tables are useful in data warehouse ETL processes, eliminating staging requirements and boosting performance through parallel querying.

Let’s guide you through the process step by step

Step 1: Create XXAA_XML directory in bin location and modify the permissions.

$ mkdir XXAA_XML
$ chmod 777 XXAA_XML
$ cd 777 XXAA_XML

$ mkdir XXAA_XML

$ chmod 777 XXAA_XML

$ cd 777 XXAA_XML

Step 2: Upload the XML files into the XXAA_XML directory

XXAA_XML]$ ls -lrt
total 8
-rw-rw-rw-. 1 oracle oracle 1208 Feb  1 07:57 sample.xml

XXAA_XML]$ ls -lrt

total 8

-rw-rw-rw-. 1 oracle oracle 1208 Feb 1 07:57 sample.xml

Step 3: Run below command to create a data file (.dat) in the bin folder

$ ls -l *.xml | awk '{print "\/XXAA_XML\/"$9}' > /u01/Middleware/ODI12c/oracle_common/bin/XXAA_XML_XT_DATA.dat
$ cat XXAA_XML_XT_DATA.dat
/XXAA_XML/sample.xml

$ ls -l *.xml | awk '{print "\/XXAA_XML\/"$9}' > /u01/Middleware/ODI12c/oracle_common/bin/XXAA_XML_XT_DATA.dat

$ cat XXAA_XML_XT_DATA.dat

/XXAA_XML/sample.xml

Step 4. Create a directory for the bin folder

CREATE OR REPLACE DIRECTORY XXAA_XT_DIR AS '/u01/Middleware/ODI12c/oracle_common/bin';
SELECT * FROM ALL_DIRECTORIES
WHERE 1=1
AND directory_name = 'XXAA_XT_DIR'

CREATE OR REPLACE DIRECTORY XXAA_XT_DIR AS '/u01/Middleware/ODI12c/oracle_common/bin';

SELECT * FROM ALL_DIRECTORIES

WHERE 1=1

AND directory_name = 'XXAA_XT_DIR'

Step 5. Create External table with above directory ‘XXAA_XT_DIR’ and SQL Loader file ‘XXAA_XML_XT_DATA.dat’

CREATE TABLE xml_tab(
FILENAME VARCHAR2(100),
XML_DATA CLOB
)
ORGANIZATION EXTERNAL(
TYPE ORACLE_LOADER
DEFAULT DIRECTORY XXAA_XT_DIR
ACCESS PARAMETERS (
FIELDS (FILENAME CHAR(100)) COLUMN TRANSFORMS (XML_DATA FROM lobfile (FILENAME)))
LOCATION ('XXAA_XML_XT_DATA.dat'))

CREATE TABLE xml_tab(

FILENAME VARCHAR2(100),

XML_DATA CLOB

)

ORGANIZATION EXTERNAL(

TYPE ORACLE_LOADER

DEFAULT DIRECTORY XXAA_XT_DIR

ACCESS PARAMETERS (

FIELDS (FILENAME CHAR(100)) COLUMN TRANSFORMS (XML_DATA FROM lobfile (FILENAME)))

LOCATION ('XXAA_XML_XT_DATA.dat'))

SELECT * FROM xml_tab;

1	SELECT * FROM xml_tab;

Reading and querying XML data in Oracle

Now that we have loaded some XML files into our Oracle database we can start querying the data. Oracle offers three options for reading and selecting data from XML

SQL/XML is the most commonly used option and should meet the vast majority of your requirements
Another option for reading XML data in Oracle are the EXTRACT and EXTRACTVALUE functions. Both of these functions are deprecated and should not be used anymore.
XQuery is for niche scenarios with complex requirements. It is very powerful but has a steep learning curve.

SQL/XML for querying XML data with XMLTABLE

SQL/XML is a standard defined by the SQL:2003 specification, which extends SQL with XML-related capabilities. It allows the integration of XML and SQL, enabling you to query and manipulate XML data using SQL.

Oracle’s SQL/XML functions provide native tools for reading XML data in Oracle.

Creating XML from tables

You can also go the other way and use the SQL/XML functions to create XML data from Oracle tables, i.e. convert a relational format to a hierarchical format.

With Oracle’s support for SQL/XML functions, developers can manage XML data alongside traditional relational data operations.

Below, you’ll find some of the most useful SQL/XML functions:

XMLQuery : This function extracts data from XML documents using XPath expressions within SQL queries.

XMLTable : This function enables you to extract data from XML documents and present it in a relational format.

XMLExists : This function checks whether an XML document contains nodes that match a specified XPath expression. It returns TRUE if at least one node exists, otherwise FALSE.

XMLAgg : This function aggregates multiple elements into a single XML element. It is commonly used with a subquery to generate XML output.

XMLCast : This function converts an XML value into another data type, such as VARCHAR2, NUMBER, DATE, etc. It’s useful for converting XML data into a more conventional data type for further processing or querying.

Examples of using XMLTABLE to query Oracle XML

In this hands-on example we use the XMLTABLE function to read XML data on the fly and flatten it into a denormalised structure. We then create database Views for reusability and sharing with other users.

XMLTABLE syntax

XMLTable maps the result of an XPath expression into rows and columns in an Oracle table. You can use it to break down an XML document into its parts and retrieve those parts in a tabular format.

XMLTABLE is super easy to use. The syntax is as follows

XMLTable(
  xmlnamespaces_clause,
  xpath_expression
  PASSING xml_data
  COLUMNS column_definition
)

XMLTable(

xmlnamespaces_clause,

xpath_expression

PASSING xml_data

COLUMNS column_definition

)

xmlnamespaces_clause: Optional. Defines XML namespaces used in the xpath_expression.

xpath_expression: An XPath expression that specifies the part of the XML to be processed.

xml_data: The XML data being queried.

column_definition: Defines the columns and their data types for the result set.

Let’s see XMLTABLE in action. We will use the sample XML file from the section about Loading XML.

Since the sample XML file contains multiple branches, we’ll have to create one view per XML branch.

View for ‘University/Faculty/Department’ branch

CREATE OR REPLACE VIEW dept_courses AS
SELECT
   uni."id" as university_id,
   faculty."id" as faculty_id,
   depts."id" as department_id,
   courses."Course" as course_name
FROM xml_tab,
  XMLTABLE(
   '/University'
   PASSING XML_DATA
    COLUMNS
   "id" VARCHAR(50) PATH '@id',
    faculty XMLTYPE PATH 'Faculty'
  ) uni,
  XMLTABLE(
   '/Faculty'
   PASSING uni.faculty
    COLUMNS
   "id" VARCHAR(50) PATH '@id',
    depts XMLTYPE PATH 'Department'
  ) faculty,
  XMLTABLE(
    '/Department'
    PASSING faculty.depts
    COLUMNS
      "id" VARCHAR(50) PATH '@id',
      courses XMLTYPE PATH 'Course'
  ) depts,
  XMLTABLE(
    '/Course'
    PASSING depts.courses
    COLUMNS
      "Course" VARCHAR(50) PATH '.'
  ) courses;

CREATE OR REPLACE VIEW dept_courses AS

SELECT

uni."id" as university_id,

faculty."id" as faculty_id,

depts."id" as department_id,

courses."Course" as course_name

FROM xml_tab,

XMLTABLE(

'/University'

PASSING XML_DATA

COLUMNS

"id" VARCHAR(50) PATH '@id',

faculty XMLTYPE PATH 'Faculty'

) uni,

XMLTABLE(

'/Faculty'

PASSING uni.faculty

COLUMNS

"id" VARCHAR(50) PATH '@id',

depts XMLTYPE PATH 'Department'

) faculty,

XMLTABLE(

'/Department'

PASSING faculty.depts

COLUMNS

"id" VARCHAR(50) PATH '@id',

courses XMLTYPE PATH 'Course'

) depts,

XMLTABLE(

'/Course'

PASSING depts.courses

COLUMNS

"Course" VARCHAR(50) PATH '.'

) courses;

Query the view :

SELECT * FROM dept_course

1	SELECT * FROM dept_course

Output-

View for ‘University/Faculty/ResearchGroup’ branch

CREATE OR REPLACE VIEW researchgrp_projects AS
SELECT
uni."id" as university_id,
faculty."id" as faculty_id,
grp."id" as research_group_id,
projects."Project" as Project_name
FROM xml_tab,
XMLTABLE(
'/University'
PASSING XML_DATA
   COLUMNS
"id" VARCHAR(50) PATH '@id',
   faculty XMLTYPE PATH 'Faculty'
) uni,
XMLTABLE(
'/Faculty'
PASSING uni.faculty
   COLUMNS
"id" VARCHAR(50) PATH '@id',
   grp XMLTYPE PATH 'ResearchGroup'
) faculty,
XMLTABLE(
   '/ResearchGroup'
   PASSING faculty.grp
   COLUMNS
 	"id" VARCHAR(50) PATH '@id',
 	projects XMLTYPE PATH 'Project'
) grp,
XMLTABLE(
   '/Project'
   PASSING grp.projects
   COLUMNS
 	"Project" VARCHAR(50) PATH '.'
) projects;

CREATE OR REPLACE VIEW researchgrp_projects AS

SELECT

uni."id" as university_id,

faculty."id" as faculty_id,

grp."id" as research_group_id,

projects."Project" as Project_name

FROM xml_tab,

XMLTABLE(

'/University'

PASSING XML_DATA

COLUMNS

"id" VARCHAR(50) PATH '@id',

faculty XMLTYPE PATH 'Faculty'

) uni,

XMLTABLE(

'/Faculty'

PASSING uni.faculty

COLUMNS

"id" VARCHAR(50) PATH '@id',

grp XMLTYPE PATH 'ResearchGroup'

) faculty,

XMLTABLE(

'/ResearchGroup'

PASSING faculty.grp

COLUMNS

"id" VARCHAR(50) PATH '@id',

projects XMLTYPE PATH 'Project'

) grp,

XMLTABLE(

'/Project'

PASSING grp.projects

COLUMNS

"Project" VARCHAR(50) PATH '.'

) projects;

Query the view :

SELECT * FROM researchgrp_projects;

1	SELECT * FROM researchgrp_projects;

Output-

View for ‘University/AdministrativeUnit’ branch

CREATE OR REPLACE VIEW admin_service AS
SELECT
uni."id" as university_id,
adminunit."id" as administrative_unit_id,
services."Service" as service
FROM xml_tab,
XMLTABLE(
'/University'
PASSING XML_DATA
   COLUMNS
"id" VARCHAR(50) PATH '@id',
   adminunit XMLTYPE PATH 'AdministrativeUnit'
) uni,
XMLTABLE(
'/AdministrativeUnit'
PASSING uni.adminunit
   COLUMNS
"id" VARCHAR(50) PATH '@id',
   services XMLTYPE PATH 'Service'
) adminunit,
XMLTABLE(
   '/Service'
   PASSING adminunit.services
   COLUMNS
 	"Service" VARCHAR(50) PATH '.'
) services;

CREATE OR REPLACE VIEW admin_service AS

SELECT

uni."id" as university_id,

adminunit."id" as administrative_unit_id,

services."Service" as service

FROM xml_tab,

XMLTABLE(

'/University'

PASSING XML_DATA

COLUMNS

"id" VARCHAR(50) PATH '@id',

adminunit XMLTYPE PATH 'AdministrativeUnit'

) uni,

XMLTABLE(

'/AdministrativeUnit'

PASSING uni.adminunit

COLUMNS

"id" VARCHAR(50) PATH '@id',

services XMLTYPE PATH 'Service'

) adminunit,

XMLTABLE(

'/Service'

PASSING adminunit.services

COLUMNS

"Service" VARCHAR(50) PATH '.'

) services;

Query the view:

SELECT * FROM admin_service;

1	SELECT * FROM admin_service;

Important note

XMLTABLE only works with the XMLTYPE data type. You can convert and typecast XML data stored in a CLOB to XMLTYPE by using XMLTYPE().

Example of using XMLTYPE()

CREATE OR REPLACE VIEW admin_service AS
SELECT
uni."id" as university_id,
adminunit."id" as administrative_unit_id,
services."Service" as service
FROM xml_tab,
XMLTABLE(
'/University'
PASSING XMLTYPE(XML_DATA)
  COLUMNS
"id" VARCHAR(50) PATH '@id',
  adminunit XMLTYPE PATH 'AdministrativeUnit'
) uni,
XMLTABLE(
'/AdministrativeUnit'
PASSING uni.adminunit
  COLUMNS
"id" VARCHAR(50) PATH '@id',
  services XMLTYPE PATH 'Service'
) adminunit,
XMLTABLE(
  '/Service'
  PASSING adminunit.services
  COLUMNS
    "Service" VARCHAR(50) PATH '.'
) services;

CREATE OR REPLACE VIEW admin_service AS

SELECT

uni."id" as university_id,

adminunit."id" as administrative_unit_id,

services."Service" as service

FROM xml_tab,

XMLTABLE(

'/University'

PASSING XMLTYPE(XML_DATA)

COLUMNS

"id" VARCHAR(50) PATH '@id',

adminunit XMLTYPE PATH 'AdministrativeUnit'

) uni,

XMLTABLE(

'/AdministrativeUnit'

PASSING uni.adminunit

COLUMNS

"id" VARCHAR(50) PATH '@id',

services XMLTYPE PATH 'Service'

) adminunit,

XMLTABLE(

'/Service'

PASSING adminunit.services

COLUMNS

"Service" VARCHAR(50) PATH '.'

) services;

Oracle EXTRACT and EXTRACTVALUE

Important note: Both EXTRACT and EXTRACTVALUE are deprecated and only available for backward compatibility. We do not recommend using EXTRACT or EXTRACTVALUE. We recommend using Oracle’s XMLTable or for more complex requirements XQuery to extract values from XML documents.

EXTRACT for XML

Using an XPATH expression in EXTRACT gives you a specific fragment of XML data.

Syntax :-

EXTRACT(XMLType_instance, XPath_string [, namespace_string ])

1	EXTRACT(XMLType_instance, XPath_string [, namespace_string ])

Example :-

CREATE TABLE XML_TABLE(
	xml_data XMLTYPE
);


INSERT INTO XML_TABLE
VALUES(
'<students>
	<student id = "101">
		<fname>John</fname>
		<lname>Doe</lname>
		<marks>98</marks>
	</student>
</students>');


SELECT
EXTRACT(XML_DATA, '/students/student/@id') ID,
EXTRACT(XML_DATA, '/students/student/fname') FIRST_NAME,
EXTRACT(XML_DATA, '/students/student/lname') LAST_NAME,
EXTRACT(XML_DATA, '/students/student/marks') MARKS
FROM XML_TABLE;

CREATE TABLE XML_TABLE(

xml_data XMLTYPE

);

INSERT INTO XML_TABLE

VALUES(

'<students>

</student>

</students>');

SELECT

EXTRACT(XML_DATA, '/students/student/@id') ID,

EXTRACT(XML_DATA, '/students/student/fname') FIRST_NAME,

EXTRACT(XML_DATA, '/students/student/lname') LAST_NAME,

EXTRACT(XML_DATA, '/students/student/marks') MARKS

FROM XML_TABLE;

EXTRACT returns four XML fragments, e.g. <lname>Doe</lname> for the LAST_NAME

The EXTRACT function can be used to extract XML fragments from XML data stored as either XMLType or CLOB.

EXTRACT also supports XML namespaces

EXTRACTVALUE

Use the EXTRACTVALUE function to extract the values of XML elements or attributes.

Syntax

EXTRACTVALUE(XMLType_instance, XPath_string [, namespace_string ])

1	EXTRACTVALUE(XMLType_instance, XPath_string [, namespace_string ])

This function takes two main arguments: an XMLType or CLOB instance and an XPath expression. The XPath expression specifies the path to the desired node within the XML document. The function returns the value of the node, which must be a single node and either a text node, attribute, or element.

Example

SELECT
EXTRACTVALUE(XML_DATA, '/students/student/@id') ID,
EXTRACTVALUE(XML_DATA, '/students/student/fname') FIRST_NAME,
EXTRACTVALUE(XML_DATA, '/students/student/lname') LAST_NAME,
EXTRACTVALUE(XML_DATA, '/students/student/marks') MARKS
FROM XML_TABLE;

SELECT

EXTRACTVALUE(XML_DATA, '/students/student/@id') ID,

EXTRACTVALUE(XML_DATA, '/students/student/fname') FIRST_NAME,

EXTRACTVALUE(XML_DATA, '/students/student/lname') LAST_NAME,

EXTRACTVALUE(XML_DATA, '/students/student/marks') MARKS

FROM XML_TABLE;

Using the @ operator you can extract the value of an element attribute: EXTRACTVALUE(XML_DATA, ‘/students/student/@id’) ID

The EXTRACTVALUE function can be used to extract values from XML data stored as either XMLType or CLOB.

EXTRACTVALUE also supports XML namespaces.

Example of using EXTRACTVALUE with XML namespaces

CREATE TABLE XMLNS_TABLE(
	xml_data CLOB
);




INSERT INTO XMLNS_TABLE
VALUES(
	'<root xmlns:f="https://www.w3schools.com/furniture">
		<f:table>
			  <f:name>African Coffee Table</f:name>
			  <f:width>80</f:width>
			  <f:length>120</f:length>
		</f:table>
	</root>'
);


SELECT
	EXTRACTVALUE(XMLTYPE(XML_DATA), '/root/f:table/f:name','xmlns:f="https://www.w3schools.com/furniture"') Name,
	EXTRACTVALUE(XMLTYPE(XML_DATA), '/root/f:table/f:width','xmlns:f="https://www.w3schools.com/furniture"') Width,
	EXTRACTVALUE(XMLTYPE(XML_DATA), '/root/f:table/f:length','xmlns:f="https://www.w3schools.com/furniture"') Length
FROM XMLNS_TABLE;

CREATE TABLE XMLNS_TABLE(

xml_data CLOB

);

INSERT INTO XMLNS_TABLE

VALUES(

'<root xmlns:f="https://www.w3schools.com/furniture">

<f:table>

<f:name>African Coffee Table</f:name>

<f:width>80</f:width>

<f:length>120</f:length>

</f:table>

</root>'

);

SELECT

EXTRACTVALUE(XMLTYPE(XML_DATA), '/root/f:table/f:name','xmlns:f="https://www.w3schools.com/furniture"') Name,

EXTRACTVALUE(XMLTYPE(XML_DATA), '/root/f:table/f:width','xmlns:f="https://www.w3schools.com/furniture"') Width,

EXTRACTVALUE(XMLTYPE(XML_DATA), '/root/f:table/f:length','xmlns:f="https://www.w3schools.com/furniture"') Length

FROM XMLNS_TABLE;

You can nest EXTRACT and EXTRACTVALUE

SELECT
  EXTRACT(XML_DATA, '/students/student/@id') ID,
  EXTRACTVALUE(EXTRACT(XML_DATA, '/students/student/fname'),'/fname') FIRST_NAME,
  EXTRACTVALUE(EXTRACT(XML_DATA, '/students/student/lname'),'/lname') LAST_NAME,
  EXTRACTVALUE(EXTRACT(XML_DATA, '/students/student/marks'),'/marks') MARKS
FROM ADMIN1.XML_TABLE;

SELECT

EXTRACT(XML_DATA, '/students/student/@id') ID,

EXTRACTVALUE(EXTRACT(XML_DATA, '/students/student/fname'),'/fname') FIRST_NAME,

EXTRACTVALUE(EXTRACT(XML_DATA, '/students/student/lname'),'/lname') LAST_NAME,

EXTRACTVALUE(EXTRACT(XML_DATA, '/students/student/marks'),'/marks') MARKS

FROM ADMIN1.XML_TABLE;

XQuery

XQuery is a functional query language for finding and extracting elements and attributes from XML documents. Think of XQuery as SQL for XML.

When to use XQuery and when to use SQL/XML

XQuery and SQL/XML functions are useful tools for handling XML data in Oracle. XQuery is perfect for complex XML manipulation. It gives precise control over elements and relationships, making it suitable for complex hierarchical structures. On the other hand, SQL/XML functions are optimal for integrating XML tasks into relational databases, particularly for simpler processing alongside traditional SQL queries. XQuery is also recommended if you have XQuery wizards on your team as you will not have the steep learning curve typically associated with XQuery.

In summary, use XQuery for complex XML conversion projects. In particular if you have in-house skills. Use SQL/XML functions such as XMLTABLE for less complex requirements and for scenarios where you need to mix and match with SQL.

XMLIndex for fast XML querying

Oracle’s XMLIndex feature is designed to improve the performance of queries on XML documents that are stored in an XML column, making it beneficial when dealing with XML data. Unlike traditional relational indexes, which rely on specific table columns for index keys, XMLIndex uses a specific XML pattern expression to index paths and values within XML documents contained in a single column. By allowing users to create indexes on XMLType columns, XMLIndex enables quicker retrieval and processing of XML data through optimised query execution paths. However, XML indexes may not be necessary for small XML documents or situations where query performance is not a critical concern.

XMLIndex and CLOB

XMLIndex only works with columns of the XMLType. Another reason to store your XML files and data in the XMLType data type.

Using an XML Index is particularly useful for the schema on read scenario as it can speed up your queries.

Example for creating an XMLIndex

CREATE INDEX xml_data_index ON xml_tab(xml_data)
INDEXTYPE IS XDB.XMLIndex;

1 2	CREATE INDEX xml_data_index ON xml_tab(xml_data) INDEXTYPE IS XDB.XMLIndex;

Converting XML to Oracle tables

In the previous section we explored how to query and read XML data stored inside an Oracle table. We exposed the data as database Views to consumers such as data analysts.

In this section we will look at how we can convert hierarchical XML and write it to relational Oracle tables.

Once converted, the relational tables will simplify the process for data consumers to query the extracted and parsed data using SQL.

We first create the DDL for the target tables and then use the Views we created in the previous section to INSERT the data to these tables.

They are then ready to be queried using SQL.

Convert XML branch ‘University/Faculty/Department’ to Oracle table

CREATE TABLE UNIVERSITY.Dept_Table(
university_id VARCHAR2(100),
faculty_id VARCHAR2(100),
department_name VARCHAR2(100),
course_name VARCHAR2(100)
)

INSERT INTO UNIVERSITY.Dept_Table
SELECT * FROM dept_courses;

SELECT * FROM UNIVERSITY.Dept_Table;

CREATE TABLE UNIVERSITY.Dept_Table(

university_id VARCHAR2(100),

faculty_id VARCHAR2(100),

department_name VARCHAR2(100),

course_name VARCHAR2(100)

)

INSERT INTO UNIVERSITY.Dept_Table

SELECT * FROM dept_courses;

SELECT * FROM UNIVERSITY.Dept_Table;

Convert XML branch ‘University/Faculty/ResearchGroup’ to Oracle table

CREATE TABLE UNIVERSITY.Research_Groups_Table(
university_id VARCHAR2(100),
faculty_id VARCHAR2(100),
research_group_id VARCHAR2(100),
project_name VARCHAR2(100)
)

INSERT INTO UNIVERSITY.Research_Groups_Table
SELECT * FROM researchgrp_projects;

SELECT * FROM UNIVERSITY.Research_Groups_Table;

CREATE TABLE UNIVERSITY.Research_Groups_Table(

university_id VARCHAR2(100),

faculty_id VARCHAR2(100),

research_group_id VARCHAR2(100),

project_name VARCHAR2(100)

)

INSERT INTO UNIVERSITY.Research_Groups_Table

SELECT * FROM researchgrp_projects;

SELECT * FROM UNIVERSITY.Research_Groups_Table;

Convert XML branch ‘University/AdministrativeUnit’ to Oracle table

CREATE TABLE UNIVERSITY.Admin_Unit_Table(
university_id VARCHAR2(100),
Administrative_unit_id VARCHAR2(100),
service VARCHAR2(100)
);

INSERT INTO UNIVERSITY.Admin_Unit_Table
SELECT * FROM admin_service;

SELECT * FROM UNIVERSITY.Admin_Unit_Table;

CREATE TABLE UNIVERSITY.Admin_Unit_Table(

university_id VARCHAR2(100),

Administrative_unit_id VARCHAR2(100),

service VARCHAR2(100)

);

INSERT INTO UNIVERSITY.Admin_Unit_Table

SELECT * FROM admin_service;

SELECT * FROM UNIVERSITY.Admin_Unit_Table;

Parsing XML from Oracle CLOB or XMLType

In this section we show you how to use Flexter to parse XML inside an Oracle CLOB or XMLType. Flexter is Sonra’s XML converter.

We first store the XML in a table with either XMLType or CLOB. Unlike Oracle which prefers XMLType, Flexter can work well with XML in either CLOB or XMLType.

INSERT INTO xml_tab (id, xml_data)
VALUES (1, XMLType('<University id="TUD">
    <Faculty id="Engineering">
        <Department id="ComputerScience">
     	<Course>Introduction to Programming</Course>
     	<Course>Algorithms and Data Structures</Course>
        </Department>
        <Department id="ElectricalEngineering">
     	<Course>Circuit Analysis</Course>
            <Course>Electromagnetics</Course>
     	<Course>Control Systems</Course>
        </Department>
        <ResearchGroup id="ArtificialIntelligence">
     	<Project>Machine Learning Advances</Project>
     	<Project>Neural Network Optimization</Project>
     	<Project>AI Ethics and Society</Project>
        </ResearchGroup>
        <ResearchGroup id="Nanotechnology">
     	<Project>Nano-materials Engineering</Project>
     	<Project>Quantum Computing</Project>
        </ResearchGroup>
    </Faculty>
    <AdministrativeUnit id="Library">
        <Service>Book Lending</Service>
        <Service>Research Assistance</Service>
    </AdministrativeUnit>
    <AdministrativeUnit id="IT">
        <Service>Campus Network</Service>
        <Service>Helpdesk</Service>
    </AdministrativeUnit>
</University>
'));

INSERT INTO xml_tab (id, xml_data)

VALUES (1, XMLType('<University id="TUD">

<Course>Introduction to Programming</Course>

<Course>Algorithms and Data Structures</Course>

</Department>

<Course>Circuit Analysis</Course>

<Course>Electromagnetics</Course>

<Course>Control Systems</Course>

</Department>

<Project>Machine Learning Advances</Project>

<Project>Neural Network Optimization</Project>

<Project>AI Ethics and Society</Project>

</ResearchGroup>

<Project>Nano-materials Engineering</Project>

<Project>Quantum Computing</Project>

</ResearchGroup>

</Faculty>

<Service>Book Lending</Service>

<Service>Research Assistance</Service>

</AdministrativeUnit>

<Service>Campus Network</Service>

<Service>Helpdesk</Service>

</AdministrativeUnit>

</University>

'));

In a first step we create a data flow with the logical target schema

We use Flexter’s command line tool to generate the relational target schema. In case you are wondering, Flexter also ships with an API. We tell Flexter that it can find the XML to generate the schema in table (-T) xml_tab and column xml_data (-C). We also tell Flexter to use the Elevate optimisation algorithm when deriving the target schema.

xml2er -g1 “jdbc:oracle:thin:@//165.23.245.239:1523/flexter” -U <user> -P <password> -T xml_tab -C xml_data

1	xml2er -g1 “jdbc:oracle:thin:@//165.23.245.239:1523/flexter” -U <user> -P <password> -T xml_tab -C xml_data

The output from this command is as follows:

# schema
schema: 5964
logical: 2405
job: 22128
# statistics
startup: 1895 ms
load: 160 ms
xpath stats: 9474 ms
doc stats: 1609 ms
parse: 123 ms
write: 9232 ms
xpaths: 12 | map:0%/0 new:100%:12
documents: 1 | suc:100%/2 part:0%/0 fail:0%/0 size:4.2KB

# schema

schema: 5964

logical: 2405

job: 22128

# statistics

startup: 1895 ms

load: 160 ms

xpath stats: 9474 ms

doc stats: 1609 ms

parse: 123 ms

write: 9232 ms

xpaths: 12 | map:0%/0 new:100%:12

documents: 1 | suc:100%/2 part:0%/0 fail:0%/0 size:4.2KB

The important information is the schema ID. This is the ID of the relational target schema which we will use in the next step when we convert the data.

This command tells Flexter to take the XML data in table xml_tab and column xml_data and use the schema ID from the previous step to convert the XML.

xml2er -x 5964 -S o “jdbc:oracle:thin:@//165.23.245.239:1523/flexter” -U <user> -P <password> -T xml_tab -C xml_data

1	xml2er -x 5964 -S o “jdbc:oracle:thin:@//165.23.245.239:1523/flexter” -U <user> -P <password> -T xml_tab -C xml_data

Flexter generates an ER diagram of the processed data.

It also generates a source to target map for data lineage

No code XML conversion to Oracle

For a more detailed example of using Flexter to automatically convert XML refer to our post on No Code XML Conversion to Oracle.

Automatically loading and converting XML to Oracle tables

We have seen how we can manually convert XML to Oracle tables by writing code. I have also shown you how to use Flexter to fully automate the process.

XML conversion tools such as Flexter automate the entire process of converting XML to Oracle tables without any manual intervention. XML converters eliminate the need to load the XML data to Oracle first. They automate schema creation, mapping, and error handling, offering a fully automated solution compared to traditional methods using Oracle’s SQL/XML extensions.

Here is a summary comparison of manual versus automated XML conversion on Oracle.

You can download the comparison as a PDF

Manual vs. automated conversion

In contrasting manual XML conversion techniques with automated processes facilitated by tools like Flexter, the advantages of automation become clear:

Complexity Management: Automated processes handle any level of XML and XSD complexity efficiently.
Accelerated Deployment: By automating the XML conversion lifecycle—including analysis, schema generation, and mappings—data is swiftly prepared for decision-making.
Risk Reduction: The automation of XML parsing mitigates the risk of project delays or budget overruns, especially in complex projects based on industry standards.
Consistency and Accuracy: Automated parsing ensures consistent and precise execution, significantly lowering the potential for human error.
Scalability: XML automation tools are designed to meet any service level agreement (SLA) and handle large volumes of XML data.
User Accessibility: The user-friendly interfaces of automated tools reduce the dependency on specialised XML skills, which are scarce and represent a vulnerability for projects.
Refactoring and schema evolution: In case your XML or XSD changes XML converters can automatically evolve your schema. You don’t have to go through a lengthy refactoring process.

When to use automated XML conversion:

While automated conversion processes have clear benefits, they must be balanced against the costs of licensing tools like Flexter. For simple requirements or occasional queries, an XML automation tool may not be necessary. However, conversion software becomes invaluable when dealing with complex XML/XSD structures, processing large or numerous types of XML files, working under strict SLAs, or operating without in-house XML expertise.

Flexter. Your solution for complex XML Conversion

If you’re facing challenges with complex XML structures, large file sizes, or tight project deadlines, consider exploring Flexter’s capabilities. Our free online version offers a glimpse into the efficiency and effectiveness of XML conversion software. For more complex inquiries, our experts are ready to discuss your XML conversion needs in detail, ensuring your XML to Oracle conversion project is a success.

Cookie	Duration	Description
__cfruid	session	Cloudflare sets this cookie to identify trusted web traffic.
cookielawinfo-checkbox-marketing	1 month	This cookie is set by the GDPR Cookie Consent plugin to store the user consent for the cookies in the category "Marketing".
cookielawinfo-checkbox-necessary	1 month	This cookie is set by GDPR Cookie Consent plugin. The cookies is used to store the user consent for the cookies in the category "Necessary".
cookielawinfo-checkbox-preferences	1 month	This cookie is set by the GDPR Cookie Consent plugin to check if the user has given consent to use cookies under the "Preferences" category.
cookielawinfo-checkbox-statistics	1 month	This cookie is set by the GDPR Cookie Consent plugin to store the user consent for the cookies in the category "Statistics".
cookielawinfo-checkbox-unclassified	1 month	This cookie is set by GDPR Cookie Consent plugin. The cookie is used to store the user consent for the cookies in the category "Unclassified".
CookieLawInfoConsent	1 month	Records the default button state of the corresponding category & the status of CCPA. It works only in coordination with the primary cookie.
csrftoken	1 year	This cookie is associated with Django web development platform for python. Used to help protect the website against Cross-Site Request Forgery attacks

Cookie	Duration	Description
AnalyticsSyncHistory	1 month	Linkedin set this cookie to store information about the time a sync took place with the lms_analytics cookie.
bcookie	2 years	LinkedIn sets this cookie from LinkedIn share buttons and ad tags to recognize browser ID.
bscookie	2 years	LinkedIn sets this cookie to store performed actions on the website.
lang	session	LinkedIn sets this cookie to remember a user's language setting.
li_gc	2 years	Linkedin set this cookie for storing visitor's consent regarding using cookies for non-essential purposes.
lidc	1 day	LinkedIn sets the lidc cookie to facilitate data center selection.
mgref	1 year	This cookie is set by Eventbrite to deliver content tailored to the end user's interests and improve content creation. It is also used for event-booking purposes.
mgrefby	1 year	This cookie is set by Eventbrite to deliver content tailored to the end user's interests and improve content creation. It is also used for event-booking purposes.
UserMatchHistory	1 month	LinkedIn sets this cookie for LinkedIn Ads ID syncing.

Cookie	Duration	Description
G	1 year	Cookie used to facilitate the translation into the preferred language of the visitor.
SERVERID	session	This cookie is set by Slideshare's HAProxy load balancer to assign the visitor to a specific server.

Cookie	Duration	Description
_ga	2 years	The _ga cookie, installed by Google Analytics, calculates visitor, session and campaign data and also keeps track of site usage for the site's analytics report. The cookie stores information anonymously and assigns a randomly generated number to recognize unique visitors.
_ga_7H38LVR4Z5	2 years	This cookie is installed by Google Analytics.
_gat_gtag_UA_44804396_1	1 minute	Set by Google to distinguish users.
_gat_UA-44804396-1	1 minute	A variation of the _gat cookie set by Google Analytics and Google Tag Manager to allow website owners to track visitor behaviour and measure site performance. The pattern element in the name contains the unique identity number of the account or website it relates to.
_gcl_au	3 months	Provided by Google Tag Manager to experiment advertisement efficiency of websites using their services.
_gid	1 day	Installed by Google Analytics, _gid cookie stores information on how visitors use a website, while also creating an analytics report of the website's performance. Some of the data that are collected include the number of visitors, their source, and the pages they visit anonymously.
CONSENT	2 years	YouTube sets this cookie via embedded youtube-videos and registers anonymous statistical data.
SIDCC	6 Months	The "SIDCC" cookie is used as security measure to protect users data from unauthorised access
test_cookie	15 minutes	The test_cookie is set by doubleclick.net and is used to determine if the user's browser supports cookies.
VISITOR_INFO1_LIVE	5 months 27 days	A cookie set by YouTube to measure bandwidth that determines whether the user gets the new or old player interface.
YSC	session	YSC cookie is set by Youtube and is used to track the views of embedded videos on Youtube pages.
yt-remote-connected-devices	never	YouTube sets this cookie to store the video preferences of the user using embedded YouTube video.
yt-remote-device-id	never	YouTube sets this cookie to store the video preferences of the user using embedded YouTube video.
yt.innertube::nextId	never	This cookie, set by YouTube, registers a unique ID to store data on what videos from YouTube the user has seen.
yt.innertube::requests	never	This cookie, set by YouTube, registers a unique ID to store data on what videos from YouTube the user has seen.

Cookie	Duration	Description
AN	1 month
AS	session
ebEventToTrack	1 month
eblang	1 year
SNID	2 years	This cookie is set by the Google. This cookie is used by the map which helps visitors to identify and reach the facility.
SP	session
SS	session

SQL Visualisation Guide - Query Diagrams, Lineage & ERD

SQL Visualisation Guide - Query Diagrams, Lineage & ERD

SQL Visualisation Guide - Query Diagrams, Lineage & ERD

SQL Visualisation Guide - Query Diagrams, Lineage & ERD

Best Way to Load & Convert XML Data to Oracle Tables

Key takeaways

Storing XML in the Oracle database

XMLType

CLOB for XML

XMLType vs. CLOB for XML

Loading XML data into an Oracle table

Inserting XML into an Oracle table

Loading XML files with SQL*Loader

Loading XML files with External Tables

Reading and querying XML data in Oracle

SQL/XML for querying XML data with XMLTABLE

Creating XML from tables

Examples of using XMLTABLE to query Oracle XML

Important note

Oracle EXTRACT and EXTRACTVALUE

EXTRACT for XML

EXTRACTVALUE

XQuery

When to use XQuery and when to use SQL/XML

XMLIndex for fast XML querying

XMLIndex and CLOB

Converting XML to Oracle tables

Parsing XML from Oracle CLOB or XMLType

No code XML conversion to Oracle

Automatically loading and converting XML to Oracle tables

Manual vs. automated conversion

When to use automated XML conversion:

Flexter. Your solution for complex XML Conversion

Further reading

Maciek

Best Way to Load & Convert XML Data to Oracle Tables

Key takeaways

Storing XML in the Oracle database

XMLType

CLOB for XML

XMLType vs. CLOB for XML

Loading XML data into an Oracle table

Inserting XML into an Oracle table

Loading XML files with SQL*Loader

Loading XML files with External Tables

Reading and querying XML data in Oracle

SQL/XML for querying XML data with XMLTABLE

Creating XML from tables

Examples of using XMLTABLE to query Oracle XML

Important note

Oracle EXTRACT and EXTRACTVALUE

EXTRACT for XML

EXTRACTVALUE

XQuery

When to use XQuery and when to use SQL/XML

XMLIndex for fast XML querying

XMLIndex and CLOB

Converting XML to Oracle tables

Parsing XML from Oracle CLOB or XMLType

No code XML conversion to Oracle

Automatically loading and converting XML to Oracle tables

Manual vs. automated conversion

When to use automated XML conversion:

Flexter. Your solution for complex XML Conversion

Further reading

Related Articles

Cookies consent
